DS18 SXE-1200.4 SXE 100W x 4-Channel Class Ab Amplifier (Black)

The DS18 SXE Amplifier Series is built for true audio enthusiasts seeking a major upgrade in their vehicle's sound performance. At the heart of the series, the SXE-1200.4 empowers your speakers to deliver their full potential capturing the finest details of your favorite music with clarity and power.
With features like a fully variable crossover, adjustable input gain sensitivity, and a versatile multi-channel design, the SXE-1200.4 gives you full control over your sound. Fine-tune your system to match your personal preferences and enjoy every beat, note, and lyric with exceptional precision.

Key Features:

• Full Range Amplifier
• 4 Channel
• Class A/B
• 2 ~ 4 Ohm Stable
• 4 x 60 Watts @ 4 Ohm
• Compact Design

Specifications:

• Total Watts (Peak): 1200W
• RMS Power @ 4 Ohm: 4 x 60W
• RMS Power @ 2 Ohm: 4 x 100W
• RMS Power @ 4 Ohm Bridge: 2 x 200W

• AUDIO
• Frequency Response: 10Hz - 20KHz
• Signal to Noise Ratio: 90dB
• Efficiency @ 4 Ohm: 64%
• Damping Factor: 170
• Input Impedance: 20kΩ
• Channel Separation: 45dB
• Total Harmonic Distortion (THD): 0.05%
• Low Level Input Range: 200mV - 5V
• Selectable X-Over: HPF / FULL / LPF
• X-Over Filter Range: 40Hz - 2KHz

• FEATURES
• Amplifier Class: Analog (AB)
• Amplifier Type: Stereo Full Range
• Number of Channels: 4
• Minimum Impedance: 2 Ohm Stereo / 4 Ohm Bridge
• LED Indicator: Power / Protect / Clip
• Power Input Terminal Size: 4Ga
• Fuse Size: 2 x 25A (50A)
• Cooling Fan: Yes
• Thermal Protection: Yes (80 °C)
• Over-Load Protection: Yes
• DC Output Protection: Yes
• Short Circuit Output Protection: Yes
• Voltage Input Protection: Yes (16.5V)
• Clipping Protection: Yes

• MEASUREMENTS
• Overall Length: 9.81" / 249.3mm
• Overall Width: 5.51" / 140mm
• Overall Height: 1.88" / 48mm
• Heatsink Length: 8.34" / 212mm
• Gross Single Unit Weight: 1.76KG
