DS18 PRO-TWX1 3.8" Super Bullet Tweeter (Black)

1" PRO Aluminum Super Bullet Tweeter €“ 240W with Built-In Capacitor Crossover (Pair)
The PRO-TWX1 tweeters are far from ordinary €”they embody DS18 €™s years of expertise and high-performance audio engineering that enthusiasts have come to rely on and love.

Features:

• 3.8" Super Bullet Tweeter
• MAX Power: 240 Watts
• RMS Power: 120 Watts
• Impedance: 4 Ohm ~ 103dB
• Ferrite Magnet
• Pair

Specifications:

• Nominal Diameter: 3.8" / 96mm
• Nominal Impedance: 4 Ohm
• AES Power Handling: 60W
• Program Power Handling: 120W
• Peak Power Handling: 240W
• Sensitivity (1w/1m): 103 dB
• Frequency Response: 3.5K-20KHz
• Recommended Hi Pass Crossover: 2KHz
• Sold In Pair or Single: Pair

• Filter (Bass Blocker): N/A
• Body Material: Aluminum
• Body Color / Finish: Black
• Faceplate Color / Finish: Black / Machined
• Bullet Material: Aluminum

• Voice Coil Diameter: 1" / 25.4mm
• Voice Coil Former Material: Kapton
• Winding Material: CCAW
• Diaphragm Material: Aluminum
• Magnet Material: Ferrite
• Magnet Weight: 8 Oz

• Overall Diameter: 3.78" / 96mm
• Overall Depth: 1.78" / 45mm
• Front Mount Baffle Cutout: 2.76" / 70mm
• Mounting Depth: 1.57" / 40mm
• Motor Diameter: 2.76" / 70mm
• Gross Single Unit Weight (lb): 3
• Single Unit Box Dimensions (W x L x H in inches): 8.5 x 4.25 x 2.25
• Quantity of Units in Master Carton: 12
• Gross Master Carton Weight (lb): 33
• Master Carton Dimensions (W x L x H in inches): 17.25 x 9.25 x 7.5
